PLEASE READ !
PLEASE READ !!
International truck can be a difficult truck to fit for a harness. From the years of 2000-2006 there could be as many as 4 seperate harness that can apply. To help insure the exact fit we would suggest to pull the radio and look at the radio harness. When you pull the radio and notice a small 12 or 16pin white plug that plugs into the radio, trace down the harness to see if there is another set of plugs. These could be the mate to a (BT00128) version or the (BT ISO DIN) version or no extra plugs at all. If one or the other exist this would be the version you will want to use. Checking this before you order or call will help insure we ship you the right harness for the truck. SEE EXAMPLE ABOVE
2800-8300 Series Med Duty Built 7/92 To 8/04
9000 Series Conventional Built 7/92 to 8/04
9000 Series Conventional Pro Sleeper From 7/94 To 8/06
2800-8300 Series Medium Duty Before 7/92
9000 Series COE
9000 Series Conventional Built Before 7/92
Medium Duty After 8/04 to present Pro Star All
16 pin plugs into mating plug approx 3/4in wide and 5/16 tall (used when no other harness is showing in truck) Does not work when the factory cassette version was installed. You might have to trim off the guides on your OEM plug so it will plug into this harness. Its okay. The harness was designed for that
One of the most confusing harness that occurs on the international is from 2000 to 2006. The factory radio was usually the Panasonic version. If your truck falls during these years we suggest to pull it and take a look to make sure you get the right harness. Once pulled you might notice a small white plug that is inserted into the back of the radio. It is approx. 5/16 - 3/4in wide. Look farther down the harness wires to see if there is another set of plugs usually the BT-00128 version. If it is there then use the BT-00128. If no other harness is there check to see what version of factory radio you have, Cassette or CD or just AM/FM. If CD buy the BT PAN CD, if AM/FM or AM/FM/CAS buy the BT PAN CAS
Need to remove your old radio for replacement? Does your old radio have 2 small holes on each side of the face? We sell the removal tool to release the factory spring retainers that hold it in place. Inserting this tool on both sides will safely and easily allow extraction. You can use other means but this is what this tool is for. Works every time.
